Integration Partner Modules-Crestron Traditional SIMPL

Device Driver(s) for various lighting (LED) control products and motor control products are currently available from Crestron. .

For lighting projects, simply launch your Crestron SIMPL Windows application and open our demo MC3 project (.smw) and review the functionality supported within our devices. Then launch your Crestron VisionTools Pro-e application to customize your user interface using our .vtp demo file for guidance. The referenced download below makes it very easy to integrate a Crestron control system with Converging Systems' lighting projects. Excellent bi-directional feedback is now available with our LED lighting control products, including color temperature and RGBW functionality. Contact Crestron for more information.

The Sample Project for which a weblink is specified below, has an updated driver updated by Converging Systems which integrates both motor LED lighting control into a single driver. It is exactly the same driver as written by Crestron except the motor control operators have been entered as "Serial I/O commands." Crestron has separate motor control and lighting control drivers, but this harmonized driver (contained within the Sample Project) is very useful where motor and lighting control is desired within the same driver.

Note: If any sample projects are provided below, they are in .zip format. Download the file, unzip and open as a new project..

Model	Interface	Functions	Sample Screens/Downloads

ILC-x00 LED Controller	IBT-100 (RS-232c)	Controls device(s) using RS-232-C communication Controls lighting state (ON/OFF) Controls lighting presets (P1-P24) Controls lighting effects (Effect #1,#2) Controls multiple zone, group, and node (Z.G.N) addresses Controls setup, dissolve rate and sequence rate Enables bi-directional feedback for color states rate	Integration Notes Module Download-V2.0 Sample SIMPL Project Sample Vision Tools Project (large download)
ILC-x00 LED Controller	e-Node (IP)	Controls device(s) using RS-232-C communication Controls lighting state (ON/OFF) Controls lighting presets (P1-P24) Controls lighting effects (Effect #1,#2) Controls multiple zone, group, and node (Z.G.N) addresses Controls setup, dissolve rate and sequence rate Enables bi-directional feedback for color states rate	Integration Notes Module Download-V2.0 Sample SIMPL Project Sample Vision Tools Project (large download)
IMC-100 Single Motor Controller	IBT-100 (RS-232c)	Controls motor direction (up,down, and stop) Controls intermediate presets Controls multiple zone, group, and node (Z.G.N) addresses Controls lighting effects (Effect #1,#2). Controls setup, browse, and help menus Controls setup, dissolve rate and sequence rate *Enables bi-directional feedback for motor location	Integration Notes Module Download-V2.0 Sample Project (large download)
IMC-100 Single Motor Controller	e-Node (IP)	Controls motor direction (up,down, and stop) Controls intermediate presets Controls multiple zone, group, and node (Z.G.N) addresses Controls lighting effects (Effect #1,#2). Controls setup, browse, and help menus Controls setup, dissolve rate and sequence rate *Enables bi-directional feedback for motor location	Integration Notes Module Download-V2.0 Sample Project (large download)
IMC-300 (BRIC I) Triple Motor Controller	Built-in Serial	Controls two separate motors digitally with up,down, and stop controls Controls third motor (traditionally a door motor) with up and down controls Controls multiple zone, group, and node (Z.G.N) addresses Controls multiple BRIC addresses (units 1-4) Controls up top 8 presets of multiple motors *Enables bi-directional feedback for motor location (MKII)	Integration Notes Module Download-V1.0 Sample Project
IMC-300 (BRIC I) Triple Motor Controller	External IP (e-Node)	Controls two separate motors digitally with up,down, and stop controls Controls third motor (traditionally a door motor) with up and down controls Controls multiple zone, group, and node (Z.G.N) addresses Controls multiple BRIC addresses (units 1-4) Controls up top 8 presets of multiple motors *Enables bi-directional feedback for motor location (MKII)	Integration Notes Module Download-V2.0 Sample Project (large download)
IMC-300 (CVM) Triple Motor Controller	Built-in IP (e-Node)	Controls two separate motors digitally with up,down, and stop controls Controls third motor (traditionally a door motor) with up and down controls Controls multiple zone, group, and node (Z.G.N) addresses Controls multiple BRIC addresses (units 1-4) Controls up top 8 presets of multiple motors *Enables bi-directional feedback for motor location (MKII) Hybrid driver--also includes LED lighting functionality for devices plugged into CS-BUS	Integration Notes Module Download-V2.0 Sample Project (large download)
