Integration Partner Modules-Key Digital

Device Driver(s) for various lighting (LED) control products are currently available from Key Digital.

Simply launch your Compass Navigator PC Software V. XXX or later and download the specified driver (see name below). Current versions will provide LED feedback on keypads and control from touchscreens. Contact Key Digital for more information.

Note: If any sample projects are provided below, they are in .zip format. Download the file, unzip and open as a new project.

Model Interface Functions Sample Screens/Downloads

ILC-x00
LED Controller		 IBT-100 (RS-232c)
  • Controls device(s) using RS-232-C communication
  • Controls lighting state (ON/OFF)
  • Controls lighting presets (P1-P24)
  • Controls lighting effects (Effect #1,#2)
  • Controls multiple zone, group, and node (Z.G.N) addresses
  • Enables bi-directional feedback for color states rate

Integration Notes


Compass Control Modules Download


Sample Project
ILC-x00
LED Controller		 e-Node (IP)
  • Controls device(s) using RS-232-C communication
  • Controls lighting state (ON/OFF)
  • Controls lighting presets (P1-P24)
  • Controls lighting effects (Effect #1,#2)
  • Controls multiple zone, group, and node (Z.G.N) addresses
  • Enables bi-directional feedback for color states rate

Integration Notes


Compass Control Modules Download


Sample Project
