Converging Systems e-Node Elan Partner Page

elan

g! System LUA Drivers (NEW) (Compatible with g!Core Modules 8.6 and later)

Download the applicable Integration Note (under your targeted hardware) to learn more about support for this hardware with Elan. These referenced drivers are a result of a new NICE initiative where NICE and Converging Systems have worked together to create the best possible devices drivers for Converging Systems' hardware. These drivers support new versions of g! core software (now available on gSC Controllers).

Note: If any sample projects are provided below, they are in .zip format. Download the file, unzip and open as a new project.

Model	Interface	Functions	Sample Screens/Downloads

ILC-x00 LED Controller	e-Node (IP)	Supports all new lighting features of new Elan 8.6 Core Controls device(s) using IP communication Controls lighting state (ON/OFF) Controls lighting presets (P1-P24) Controls lighting effects (Effect #1,#2) Controls multiple zone, group, and node (Z.G.N) addresses Controls setup, dissolve rate and sequence rate Enables bi-directional feedback for color states rate Enables Auto-Discovery of connected devices to an e-Node dramatically reducing programming time by integrator Supports all new lighting features of new NICE 8.6 Corer	Integration Notes (Core 8.6 and newer) Integration Notes (Core 8.2.509 to Core 8.5) Integration Notes (Core 8.1) Module Download Custom Keypad Templates Sample Project Creating Custom Effects Circadian Lighting
ILC-x00 LED Controller	IBT-100 (RS-232c)	Supports all new lighting features of new Elan 8.6 Core Controls lighting state (ON/OFF) Controls lighting Effects Controls lighting presets (P1-P24) Controls HSB Color Selectors(ILC-100c and ILC-400c) Controls Customizable Scenes Controls Correlated Color Temperature (CCT) (ILC-100c and ILC-400c) Controls Circadian Rhythm Functions (with ILC-400) Controls RGB amd RGBW Color Selectors (ILC-100 and ILC-400c) Controls multiple zone, group, and node (Z.G.N) addresses Enables bi-directional feedback for color states rate	Integration Notes (Core 8.6 and newer) Integration Notes (Core 8.2.509 to Core 8.5) Module Download Custom Keypad Templates Sample Project Creating Custom Effects Circadian Lighting
IMC-100 Single Motor Controller	e-Node (IP)	Controls motor direction (up,down, and stop) Controls multiple zone, group, and node (Z.G.N) addresses *Enables bi-directional feedback for motor location	Integration Notes Module Download [Schema 11 Core 7.3 and later] Custom Keypad Templates Sample Project
IMC-100 Single Motor Controller	IBT-100 (RS-232c)	Controls motor direction (up,down, and stop) Controls intermediate presets Controls multiple zone, group, and node (Z.G.N) addresses Controls lighting effects (Effect #1,#2). Controls setup, browse, and help menus Controls setup, dissolve rate and sequence rate *Enables bi-directional feedback for motor location	Integration Notes Module Download [Schema 11 Core 7.3 and later] Custom Keypad Templates Sample Project
IMC-300 (BRIC I) Triple Motor Controller	Built-in Serial	Controls two separate motors digitally with up,down, and stop controls Controls third motor (traditionally a door motor) with up and down controls Controls multiple zone, group, and node (Z.G.N) addresses Controls multiple BRIC addresses (units 1-4) Controls up top 8 presets of multiple motors *Enables bi-directional feedback for motor location (MKII)	Integration Notes Module Download [Schema 11 Core 7.3 and later] Custom Keypad Templates Sample Project
IMC-300 (BRIC I) Triple Motor Controller	External IP (e-Node)	Controls two separate motors digitally with up,down, and stop controls Controls third motor (traditionally a door motor) with up and down controls Controls multiple zone, group, and node (Z.G.N) addresses Controls multiple BRIC addresses (units 1-4) Controls up top 8 presets of multiple motors *Enables bi-directional feedback for motor location (MKII)	Integration Notes Module Download [Schema 11 Core 7.3 and later] Custom Keypad Templates Sample Project
